FEP Insulated Wire with Rated Voltage AC 600V Oil Resistant and Strong Acid Resistant Properties

305
MOQ
FEP Insulated Wire with Rated Voltage AC 600V Oil Resistant and Strong Acid Resistant Properties
fitur Galeri Deskripsi Produk Quote request suatu
fitur
Spesifikasi
Bahan konduktor: Kawat tembaga kaleng, kawat Tembaga Berlapis Perak
Bahan isolasi: Terisolasi FEP
Tipe Konduktor: Terdampar atau Padat
Nomor Inti: Inti Tunggal, 2 Inti, 3 Inti, 4 Inti, 5 Inti
Suhu kerja: -65°C ~ +200°C
Nilai Tegangan: AC 600V atau Lebih Rendah
Warna: Hitam, Putih, Biru, Merah, Kuning, Hijau, Transparan, Kuning/Hijau
Pengukur kawat: 36AWG hingga 8AWG
Luas penampang: 0,013mm2 hingga 8mm2
OD Maks: 0,65 mm hingga 7,3 mm
Perisai: Kawat tembaga kaleng menanam
Struktur konduktor: 7/0,05mm hingga 133/0,28mm
Kisaran Suhu: -65°C hingga +200°C
Peringkat tegangan: 600V atau Di Bawah
Jenis isolasi: FEP, PFA, PTFE, ETFE
Menyoroti:

Rated Voltage AC 600V FEP Insulated Wire

,

Oil Resistant FEP Cable

,

Strong Acid Resistant FEP Electric Wire
Informasi dasar
Tempat asal: Hunan, Tiongkok
Nama merek: Sanco cable
Nomor model: Seri AF-200
Syarat-syarat pembayaran & pengiriman
Deskripsi Produk
FEP Insulated High Temp Electric Cable Wire
Applications
FEP wire features excellent corrosion resistance, oil resistance, strong acid/alkali resistance, and oxidation resistance. It offers superior electrical insulation performance with high voltage resistance, low frequency loss, moisture resistance, and insulation stability. The wire is fire-resistant, aging-resistant, and has a long service life.
Electronic Industry: Temperature compensation wire, low/high temperature heating wire, aging-resistant wire, and flame-retardant wire.
Household Appliances: Internal wiring for air conditioners, microwave ovens, electronic sterilizers, rice cookers, electric kettles, heaters, ovens, frying pans, and lighting fixtures.
Product Features
  • Wear and scratch resistant
  • Easy to strip
  • High and low temperature resistant (-65°C to +200°C)
  • Anti-aging and corrosion resistant
  • Electromagnetic interference resistant
Cable Structure
Insulation FEP, PFA, PTFE, ETFE
Number of Cores Single Core, 2 Cores, 3 Cores, 4 Cores, 5 Cores
Size 0.05mm² to 8mm²
Conductor Type Solid core or stranded
Conductor Materials Silver-plated copper or tinned copper wire
Shielding Tinned copper wire weave shielded
Temperature Range -65°C to +200°C
Rated Voltage 600V or below
Color Multiple standard colors available
FEP Insulated Wire with Rated Voltage AC 600V Oil Resistant and Strong Acid Resistant Properties 0
Product Types
Type Name
AF-200 Silver Plated Copper Core FEP Insulation Install Wire
AF-200-1 Tin Plated Copper Core FEP Insulation Install Wire
AFP-200 Tin/Silver Plated Copper Core FEP Insulation Shield Install Wire
AFS-200 Tin/Silver Plated Copper Core FEP Insulation Stranded Install Wire
AFSP-200 Tin/Silver Plated Copper Core FEP Insulation Stranded Shield Install Wire
Technical Specifications
Wire Gauge Cross-section Area Conductor Structure Max. OD of Cable
36AWG 0.013mm² 7/0.05mm 0.65-1.3mm
32AWG 0.035mm² 7/0.08mm 0.75-1.4mm
30AWG 0.05mm² 7/0.10mm 0.85-1.6mm
28AWG 0.07mm² 7/0.12mm 0.9-1.65mm
26AWG 0.14mm² 7/0.16mm 1.1-1.95mm
24AWG 0.2mm² 19/0.12mm 1.2-1.98mm
22AWG 0.35/0.40mm² 19/0.16mm 1.4-2.2mm
20AWG 0.5mm² 19/0.18mm 1.6-2.4mm
18AWG 1mm² 19/0.26mm 2-2.9mm
16AWG 1.2mm² 19/0.28mm 2.2-3.1mm
14AWG 2mm² 19/0.37mm 2.7-3.6mm
12AWG 3mm² 37/0.32mm 3.6-4.6mm
10AWG 5mm² 37/0.41mm 4.5-5.6mm
8AWG 8mm² 133/0.28mm 6-7.3mm
Note: Specifications and core numbers can be customized beyond these standard options.
FEP Insulated Wire with Rated Voltage AC 600V Oil Resistant and Strong Acid Resistant Properties 1 FEP Insulated Wire with Rated Voltage AC 600V Oil Resistant and Strong Acid Resistant Properties 2
Label:

Kawat Terisolasi FEP Inti Tunggal

Kawat Terisolasi FEP Kaleng

Kawat Terisolasi FEP high temperature
